Reactor Lab Directory
This is a list of the current modules in the Lab with some screen shots.
*NOTE* The window images shown below do not show
changes made as of version 3.2.0, posted 17-Sep-2000, in which length, area
and volume units were changed to m, m2 and m3, respectively,
and additional input variables were added to some labs.
Division 1, Isothermal Reactors
- Nth Order Reactions: Batch, CSTR, PFR, each with a Quiz
- Variable Volume Batch, with Quiz
- Variable Pressure Batch, with Quiz
- Variable Flow Rate PFR, with Quiz
- Reversible Reactions: Batch, CSTR, PFR, each with a Quiz
- Reactor Networks. Windows screen shot
(click browser Back button to return here)
Division 2, Catalytic Reactors
- Intrapellet Concentration Profiles
*NOTE* Changed to spherical pellet 22-Sep-00 and
current screen shot not updated yet.
- First Order Reaction: Batch, CSTR, PFR, each with a Quiz
- Methanol Synthesis
- Glucose Oxidation in 3-phase slurry reactor
- Photocatalytic Filter Windows screen shot
(click browser Back button to return here)
Division
3, Thermal Effects
- Sulfur Dioxide Oxidation (reversible exothermic reaction in
adiabatic reactor)
- PFR With Heat Exchange, with Quiz
- Steady State CSTR, with Quiz
- Dynamic CSTR
- Adiabatic Reaction Calorimeter Windows screen shot
(click browser Back button to return here)
Division
4, Flow Patterns
- PFR CSTR Comparison
- Packed Bed RTD
Division
5, Multiple Reactions
- Stoichiometry
- Selective Ethylene Oxidation
- Parallel Reactions in a dynamic fed batch reactor
- Series Reactions in a dynamic fed batch reactor
Division
6, Electrochemical Reactors
- Fuel Cell
- Hydrogen-oxygen fuel cell simulation
